PELCO® X-TREME Cases
The PELCO® X-TREME Cases are very strong and rugged plastic boxes to protect the contents. These sturdy and robust boxes are watertight, dustproof and crushproof. They are ideal as shipping, transport and storage cases with locking clasps, strong hinge and a soft silicone O-ring seal between the base and the lid. Applications are to safely store small and or delicate equipment, samples, assemblies or parts. The larger cases have a fold down handle and a pressure equalization valve. The larger PELCO® X-TREME cases are very suitable as transport cases on field trips to store either equipment or samples.
Available in five rugged smaller sizes in clear polycarbonate plastic and four robust larger sizes made of black ABS plastic. For the four larger cases there is an optional foam insert available. The case number designation are the nearest rounded internal volume in cubic inches.
| Product# | Case# | Inside size " | Outside size " | Color | Material | Handle | Valve | Foam Insert |
|---|---|---|---|---|---|---|---|---|
| 140-80C | C8 | 3.93x2.39x0.94 | 4.40x3.05x1.40 | Clear | Polycarbonate | - | - | - |
| 140-81C | C25 | 6.00 x 3.41 x 1.19 | 6.47 x 4.13 x 1.64 | Clear | Polycarbonate | - | - | - |
| 140-82C | C50 | 6.00 x 3.41 x 2.77 | 6.47 x 4.13 x 3.26 | Clear | Polycarbonate | - | - | - |
| 140-83C | C45 | 7.88 x 3.90 x 1.42 | 8.38 x 4.66 x 1.88 | Clear | Polycarbonate | - | - | - |
| 140-84C | C110 | 7.88 x 3.90 x 3.53 | 8.38 x 4.66 x 3.99 | Clear | Polycarbonate | - | - | - |
| 140-87B | B275 | 9.37 x 7.24 x 4.06 | 10.19 x 8.55 x 4.78 | Black | ABS | x | x | Option |
| 140-88B | B400 | 9.37 x 7.24 x 6.08 | 10.19 x 8.55 x 6.80 | Black | ABS | x | x | Option |
| 140-89B | B450 | 11.93 x 9.02 x 4.05 | 12.81 x 10.36 x 4.64 | Black | ABS | x | x | Option |
| 140-90B | B650 | 11.93 x 9.02 x 5.98 | 12.81 x 10.36 x 6.64 | Black | ABS | x | x | Option |
